Automating Azure VM Snapshots

Azure Virtual Machine (VM) Snapshots provide a quick and efficient way to capture the current state of a virtual machine’s disk. Snapshots are useful for data recovery, testing, and disaster recovery strategies. However, they differ from full backups in terms of their purpose, storage mechanism, and recovery processes.

Difference Between Snapshots and Backups

Understanding Azure VM Snapshots

What is an Azure VM Snapshot?

A snapshot in Azure is a read-only copy of a disk at a specific point in time. It is often used for point-in-time recovery, disk cloning, or troubleshooting.

How Snapshots Work in Azure

Azure VM Snapshots operate at the disk level, meaning they only capture the state of a managed disk rather than the entire VM. This means that additional configurations, such as networking and VM settings, are not included in a snapshot.

Types of Snapshots in Azure

1. Full Snapshots – A complete copy of the disk, requiring significant storage.
2. Incremental Snapshots – Only capture changes since the last snapshot, making them cost-effective.

Snapshot Storage Considerations

• Stored in the same region as the managed disk.
• Incremental snapshots reduce storage costs.
• Can be copied to different regions for disaster recovery.

Creating and Managing Snapshots

Creating a Snapshot

Using the Azure Portal

1. Navigate to Azure Portal → Disks.
2. Select the managed disk you want to snapshot.
3. Click Create Snapshot.
4. Provide a name and select Incremental or Full Snapshot.
5. Click Create.

Using Azure CLI

1

az snapshot create --name MySnapshot --resource-group MyResourceGroup --source /subscriptions/{subscriptionId}/resourceGroups/{resourceGroupName}/providers/Microsoft.Compute/disks/{diskName} --location eastus

Using PowerShell

1

New-AzSnapshot -ResourceGroupName "MyResourceGroup" -SnapshotName "MySnapshot" -SnapshotConfig $snapshotConfig

Restoring from a Snapshot

1. Create a new managed disk from the snapshot.
2. Attach the disk to a new or existing VM.
3. Boot the VM and verify the data.

Deleting Snapshots

To delete a snapshot:

1

az snapshot delete --name MySnapshot --resource-group MyResourceGroup

Best Practices for Using Snapshots

When to Use Snapshots vs. Backups

• Use snapshots for temporary changes and quick rollbacks.
• Use backups for long-term recovery and disaster planning.

Cost Optimization Strategies

• Prefer incremental snapshots over full snapshots.
• Delete old snapshots regularly.
• Store snapshots in lower-cost storage tiers when applicable.

Managing Snapshots Efficiently

• Tag snapshots for easy identification.
• Automate retention policies.
• Replicate snapshots across regions for redundancy.

Security Considerations

• Restrict access using Azure Role-Based Access Control (RBAC).
• Encrypt snapshots using Azure Disk Encryption.

Automating Snapshots with Azure

Using Azure Automation

• Schedule snapshot creation with Azure Automation Runbooks.
• Example PowerShell script for automation:

1
2
3

$VM = Get-AzVM -ResourceGroupName "MyResourceGroup" -Name "MyVM"
$SnapshotConfig = New-AzSnapshotConfig -SourceUri $VM.StorageProfile.OsDisk.ManagedDisk.Id -Location "EastUS" -CreateOption Copy
New-AzSnapshot -ResourceGroupName "MyResourceGroup" -SnapshotName "AutoSnapshot" -SnapshotConfig $SnapshotConfig

Here is a more advanced PowerShell function that you can use to create snapshots for OS and Data Disks, and Assign tags to each snapshot:

With an easy fix, you can also make this function to loop different Subscriptions and VM Names.

Using Azure Logic Apps

• Create event-based snapshot scheduling with Logic Apps.
• Configure a Logic App to trigger a snapshot before critical updates.

Setting Up Policies with Azure Policy

• Enforce snapshot retention policies.
• Ensure compliance with regulatory requirements.

Use Cases and Real-World Scenarios

Temporary Snapshots Before Updates or Changes

Before applying critical updates to a VM, take a snapshot to allow rollback in case of failure.

Disaster Recovery Scenarios

• Snapshots serve as a quick rollback option after accidental deletions or system crashes.
• Snapshots stored in different regions act as a disaster recovery solution.

Cloning VMs from Snapshots

• Snapshots can be used to create identical VMs for testing or scaling environments.

Troubleshooting and Debugging

• If an application on a VM fails unexpectedly, a snapshot can be used to investigate the issue.

Common Issues and Troubleshooting

Snapshot Creation Failures

• Insufficient Permissions – Ensure the user has the correct RBAC permissions.
• Disk is in Use – Verify that the disk is not currently being modified.

Performance Impact of Snapshots

• Too many snapshots can impact VM performance; delete unnecessary snapshots promptly.

Issues with Restoring from Snapshots

• Ensure snapshots are properly converted into managed disks before attaching to VMs.

Conclusion

Azure VM Snapshots provide a fast and efficient way to capture a point-in-time state of a disk, making them invaluable for temporary rollbacks, disaster recovery, and testing scenarios. While they are not a replacement for full backups, they complement Azure Backup solutions by offering a more lightweight and flexible alternative for short-term recovery needs. Best practices such as leveraging incremental snapshots, automating retention policies, and ensuring security through encryption and access controls can help optimize costs and efficiency. By understanding how to create, manage, and automate snapshots, organizations can enhance their cloud resilience and improve operational continuity.

Vukasin Terzic
